Note:?HDD not included.
Description:
This 4CH?1080P?DVR video recorder
Features H.264+ video compression,?P2P cloud function, supporting android/iOS devices remote view anywhere anytime.?It is also with functions of motion detection,?dual-stream encoding,?which is widely used at home,?shop,?office and other surveillance needed places.
Features:
1080P
This surveillance DVR
Features uncompressed, latency free, point-to-point raw data, 2.0 Megapixel Pro HD video transmission up to 1920 x 1080p @ 30fps.
Wide Compatibility
This DVR recorder supports analog cameras and IP cameras since support with limited compatibility to third-party IP cameras. Supports NVR, AHD, analog cameras, CVI, TVI.
Customized Motion Zones & Instant Alerts
The DVR security system detects moving objects and trigger alerts when dangers occur. It will inform you in real time when invasion happens.
Plug and Play
This Hybrid DVR transmits video, audio, and controls over single coaxial cable. Utilizes your existing coaxial cable networks, reducing the need to run new cables to your Security System. H.264+ Compression Technology allows video files to be compressed without any noticeable difference in quality.
Multiple Recording/Playback Modes
The playback feature of this video recorder allows you to know the whole events, replay significant evidence or funny video records. You can quickly search for any event that happened at any time.
Specification:
Operating System: Embedded Linux System
Menu Display: 1/4 Screen
Video Code: H.264+
Main processor: Hi3520D V200
Record Resolution: Encode ability:4*1080P(5 in 1), Decode ability:4*1080P(5 in 1), 960P/720P
Multi-mode input: Analog: 4*1080P(5 in1);4*720P;4*960P
Network:8*1080P;12*960P;8*720P;4*1080P;4*720P;1*1080P
Motion detection: Each screen can be set to 192 (16 * 12) detection areas; multi-level sensitivity can be set (Limited local channel)
VGA Resolution: 1920*1080, 1440*900,1280*1024,1024*768,1280*960
Video storage: HDD,network
Backup mode: Network,USB hard disk,USB burner,SATA burner
Wireless: 3G,WIFI(extend via USB)
Signal System: PAL/NTSC
Frame Rate: 1-30fps (NTSC), 1-25fps (PAL)
HDD Supported: Support Up to 4T (The hard drive disk not included)
OSD Language: English, French, German, Spanish, Italian, Japanese, etc
Power supply: 12V/2A
Item size: 25.4 * 21.2 * 4.1cm /10 * 8.35 * 1.61in(L * W * H)
Item weight: Approx.661g /23.32oz
Package List:
1 * DVR(HDD not Included) OR1 * 4CH 1080P/960P/720P DVR Video Recorder(HDD not Included) CAN BE CHOOSE
1 * Power Adapter
1 * USB Mouse
1 * Bag of Screws
1 * English User Manual
